7038CD/HCP4A o'ta aniq burchakli kontaktli rulmanli spetsifikatsiya
| Belgilanish | 7038-CD/HCP4A | |
| Turkum | ||
| Burchakli kontaktli rulman, o'ta aniqlik | ||
| O'lchamlari | ||
| d (teshik diametri) | 190 mm | 6,299 dyuym |
| D (tashqi diametri) | 290 mm | 8,661 dyuym |
| B (kenglik) | 46 mm | 1,102 dyuym |
| Vt (vazn) | 8,03 kg | 5,95 funt |
| Texnik ma'lumotlar | ||
| Cr (kN) Asosiy dinamik yuk ko'rsatkichi | 247 | |
| C0r (kN) Asosiy statik yuk ko‘rsatkichi | 305 | |
| Charchoq yuk chegarasi (kN) | 6.1 | |
| Yog 'moylash uchun erishiladigan tezlik (r/min) | 5600 | |
| Yog '-havo moylash uchun erishiladigan tezlik (r/min) | 9000 | |
| Aloqa burchagi | 15 daraja | |
| To'pning diametri (mm) | 30,162 mm | |
| To'plar soni | 22 | |
| Yo'naltiruvchi moy miqdori | 114 sm3 | |
| Muhr | Yo'q | |
| Aniqlik | P4A | |
Kengaytirilgan 7038.CD.HCP4A burchakli aloqa sharli podshipnik 190*290*46
| Belgilanish | Asosiy o'lchamlar | Asosiy yuk ko'rsatkichlari | Erishiladigan tezliklar | ||||
| dinamik | statik | Yog 'moylash | Yog '-havo moylash | ||||
| d[mm] | D[mm] | B[mm] | C[kN] | K0[kN] | [r/min] | [r/min] | |
| 7038 ACD/HCP4A | 190 | 290 | 46 | 234 | 290 | 5 300 | 8 000 |
| 7038 ACD/HCP4AH1 | 190 | 290 | 46 | 234 | 290 | 5 300 | 8 000 |
| 7038 ACD/P4A | 190 | 290 | 46 | 234 | 290 | 4 300 | 6 300 |
| 7038 ACD/P4AH1 | 190 | 290 | 46 | 234 | 290 | 4 300 | 6 300 |
| 7038 CD/HCP4A | 190 | 290 | 46 | 247 | 305 | 5 600 | 9 000 |
| 7038 CD/HCP4AH1 | 190 | 290 | 46 | 247 | 305 | 5 600 | 9 000 |
| 7038 CD/P4A | 190 | 290 | 46 | 247 | 305 | 4 800 | 7 000 |
| 7038 CD/P4AH1 | 190 | 290 | 46 | 247 | 305 | 4 800 | 7 000 |
