7005CE / HCP4AL1super aniqlikdagi burchakli aloqa bilyali rulmanning spetsifikatsiyasi
| Belgilash | 7005-Idoralar / HCP4AL1 | |
| Turkum | ||
| Burchakli kontaktli rulman, o'ta aniqlik | ||
| O'lchamlari | ||
| d (teshik diametri) | 25 mm | 0,984 dyuym |
| D (tashqi diametri) | 47 mm | 1,654 dyuym |
| B (kenglik) | 12 mm | 0,354 dyuym |
| V (vazn) | 0,065 kg | 0,079 funt |
| Texnik ma'lumotlar | ||
| Cr (kN) Asosiy dinamik yuk darajasi | 8.32 | |
| C0r (kN) Asosiy statik yuk darajasi | 4.15 | |
| Charchoqning yuk chegarasi (kN) | 0.127 | |
| Yog 'moylash uchun erishiladigan tezlik (min / min) | 56 000 | |
| Yog 'havosini moylash uchun erishiladigan tezlik (min / min) | 85 000 | |
| Aloqa burchagi | 15 ° | |
| To'p diametri (mm) | 6,35 mm | |
| To'plar soni | 14 | |
| Yog 'miqdori | 1,3 sm3 | |
| Muhr | Yo'q | |
| Aniqlik | P4A | |
Kengaytirilgan7005. BC.HCP4AL1burchakli aloqa rulmanlari
| Belgilash | Asosiy o'lchovlar | Asosiy yuk ko'rsatkichlari | Muvaffaqiyatli tezlik | ||||
| dinamik | statik | Yog 'moyi | Yog 'havosini moylash | ||||
| d [mm] | D [mm] | B [mm] | C [kN] | C0 [kN] | [r / min] | [r / min] | |
| 7005 ACE / P4AL | 25 | 47 | 12 | 7.93 | 3.9 | 42 000 | 63 000 |
| 7005 ACE / P4AL1 | 25 | 47 | 12 | 7.93 | 3.9 | 42 000 | 63 000 |
| 7005 ACE / HCP4AH1 | 25 | 47 | 12 | 7.93 | 3.9 | 50 000 | 75 000 |
| 7005 ACE / HCP4AL | 25 | 47 | 12 | 7.93 | 3.9 | 50 000 | 75 000 |
| 7005 ACE / HCP4AL1 | 25 | 47 | 12 | 7.93 | 3.9 | 50 000 | 75 000 |
| 7005 milodiy / P4AH1 | 25 | 47 | 12 | 8.32 | 4.15 | 46 000 | 70 000 |
| 7005 milodiy / P4AL | 25 | 47 | 12 | 8.32 | 4.15 | 46 000 | 70 000 |
| 7005 milodiy / P4AL1 | 25 | 47 | 12 | 8.32 | 4.15 | 46 000 | 70 000 |
| 7005 milodiy / HCP4AH1 | 25 | 47 | 12 | 8.32 | 4.15 | 56 000 | 85 000 |
| 7005 Idoralar / HCP4AL | 25 | 47 | 12 | 8.32 | 4.15 | 56 000 | 85 000 |
| 7005 Idoralar / HCP4AL1 | 25 | 47 | 12 | 8.32 | 4.15 | 56 000 | 85 000 |
| 7005 ACD / P4AH | 25 | 47 | 12 | 9.23 | 5 | 34 000 | 50 000 |
| S7005 ACD / P4A | 25 | 47 | 12 | 9.23 | 5 | 34 000 | |
